Replacement Parts for the Easy-Fit Compression fittings Range.
Features & Benefits
Fitting sizes 16mm to 63mm Maximum Working Pressure; 16 Bar (1600 kPa, 235 psi) at 20 degrees C.
Fitting sizes 75mm to 100mm Maximum Working Pressure; 12.5 bar (1250 kPa, 182 psi) at 20 degrees C.
Hansen does not recommend the use of any Hansen Easy Fit Fittings under any driveways, paths, or foundations.
Hansen does not recommend the use of any Hansen Easy Fit Fittings under any driveways, paths or foundations.
Yes, Hansen Easy Fit Rural Compression Fittings are full compatible with these pipes.
Yes, Hansen Easy Fit Rural Compression Fittings are full compatible with Rural Plus® polyethylene pipe.
Yes, Hansen Easy Fit MD Compression Fittings are potable (drinking) water approved.
Yes, all Hansen manufactured products carry our Hansen Warranty.
For more information about the Hansen Warranty, please visit the Legal Information link in the footer.
By inside pipe diameter.
Up to 1-1/4" just tighten hand tight and all sizes above use a spanner or poly grips to tighten a further half turn. Remember the hydraulic seal is created by fully seating the Insert/O-Ring in the fitting.
Up to 32mm just tighten hand tight and all sizes above use a spanner to tighten another ½ to 1 turns past hand tight. Remember you already have a seal once the pipe is past the O-ring, all the nut is doing is compressing the grip ring onto the pipe to hold the pipe in place.
A Hansen Easy Fit Rural Compression Fitting will fit 19 – 50mm Rural Class B Pipe.
Hansen Easy Fit Rural Compression Fittings can be installed above and below the ground as long as they are supported.
